前言

你是否还在为权限管理发愁？手写拦截器、过滤器、权限判断？Spring Security 来拯救你了！

作为 Java 生态中最强大的安全框架，Spring Security 为企业级应用提供了完整的安全解决方案。本文带你从零掌握 Spring Security。

一、Spring Security 是什么？

Spring Security 是一个功能强大且高度可定制的认证和访问控制框架，专注于为 Java 应用程序提供安全服务。

1.1 核心功能

二、技术组成分布

#mermaid-svg-LQvXvlwP0oWbAN6v{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;fill:#333;}@keyframes edge-animation-frame{from{stroke-dashoffset:0;}}@keyframes dash{to{stroke-dashoffset:0;}}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-animation-slow{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 50s linear infinite;stroke-linecap:round;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-animation-fast{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 20s linear infinite;stroke-linecap:round;}#mermaid-svg-LQvXvlwP0oWbAN6v .error-icon{fill:#552222;}#mermaid-svg-LQvXvlwP0oWbAN6v .error-text{fill:#552222;stroke:#552222;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-thickness-normal{stroke-width:1px;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-thickness-thick{stroke-width:3.5px;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-pattern-solid{stroke-dasharray:0;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-thickness-invisible{stroke-width:0;fill:none;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-pattern-dashed{stroke-dasharray:3;}#mermaid-svg-LQvXvlwP0oWbAN6v .edge-pattern-dotted{stroke-dasharray:2;}#mermaid-svg-LQvXvlwP0oWbAN6v .marker{fill:#333333;stroke:#333333;}#mermaid-svg-LQvXvlwP0oWbAN6v .marker.cross{stroke:#333333;}#mermaid-svg-LQvXvlwP0oWbAN6v svg{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;}#mermaid-svg-LQvXvlwP0oWbAN6v p{margin:0;}#mermaid-svg-LQvXvlwP0oWbAN6v .pieCircle{stroke:#000000;stroke-width:2px;opacity:0.7;}#mermaid-svg-LQvXvlwP0oWbAN6v .pieOuterCircle{stroke:#000000;stroke-width:1px;fill:none;}#mermaid-svg-LQvXvlwP0oWbAN6v .pieTitleText{text-anchor:middle;font-size:25px;fill:#000000;font-family:\”trebuchet ms\”,verdana,arial,sans-serif;}#mermaid-svg-LQvXvlwP0oWbAN6v .slice{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;fill:#000000;font-size:17px;}#mermaid-svg-LQvXvlwP0oWbAN6v .legend text{fill:#000000;font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:17px;}#mermaid-svg-LQvXvlwP0oWbAN6v :root{–mermaid-font-family:\”trebuchet ms\”,verdana,arial,sans-serif;}

30%

25%

20%

15%

10%

Spring Security 学习重点分布

认证机制 [30]

授权控制 [25]

过滤器链 [20]

JWT集成 [15]

OAuth2 [10]

三、认证流程解析

3.1 请求处理流程

#mermaid-svg-O4FZnxZvbM5x5neh{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;fill:#333;}@keyframes edge-animation-frame{from{stroke-dashoffset:0;}}@keyframes dash{to{stroke-dashoffset:0;}}#mermaid-svg-O4FZnxZvbM5x5neh .edge-animation-slow{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 50s linear infinite;stroke-linecap:round;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-animation-fast{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 20s linear infinite;stroke-linecap:round;}#mermaid-svg-O4FZnxZvbM5x5neh .error-icon{fill:#552222;}#mermaid-svg-O4FZnxZvbM5x5neh .error-text{fill:#552222;stroke:#552222;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-thickness-normal{stroke-width:1px;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-thickness-thick{stroke-width:3.5px;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-pattern-solid{stroke-dasharray:0;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-thickness-invisible{stroke-width:0;fill:none;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-pattern-dashed{stroke-dasharray:3;}#mermaid-svg-O4FZnxZvbM5x5neh .edge-pattern-dotted{stroke-dasharray:2;}#mermaid-svg-O4FZnxZvbM5x5neh .marker{fill:#333333;stroke:#333333;}#mermaid-svg-O4FZnxZvbM5x5neh .marker.cross{stroke:#333333;}#mermaid-svg-O4FZnxZvbM5x5neh svg{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;}#mermaid-svg-O4FZnxZvbM5x5neh p{margin:0;}#mermaid-svg-O4FZnxZvbM5x5neh .label{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;color:#333;}#mermaid-svg-O4FZnxZvbM5x5neh .cluster-label text{fill:#333;}#mermaid-svg-O4FZnxZvbM5x5neh .cluster-label span{color:#333;}#mermaid-svg-O4FZnxZvbM5x5neh .cluster-label span p{background-color:transparent;}#mermaid-svg-O4FZnxZvbM5x5neh .label text,#mermaid-svg-O4FZnxZvbM5x5neh span{fill:#333;color:#333;}#mermaid-svg-O4FZnxZvbM5x5neh .node rect,#mermaid-svg-O4FZnxZvbM5x5neh .node circle,#mermaid-svg-O4FZnxZvbM5x5neh .node ellipse,#mermaid-svg-O4FZnxZvbM5x5neh .node polygon,#mermaid-svg-O4FZnxZvbM5x5neh .node path{fill:#ECECFF;stroke:#9370DB;stroke-width:1px;}#mermaid-svg-O4FZnxZvbM5x5neh .rough-node .label text,#mermaid-svg-O4FZnxZvbM5x5neh .node .label text,#mermaid-svg-O4FZnxZvbM5x5neh .image-shape .label,#mermaid-svg-O4FZnxZvbM5x5neh .icon-shape .label{text-anchor:middle;}#mermaid-svg-O4FZnxZvbM5x5neh .node .katex path{fill:#000;stroke:#000;stroke-width:1px;}#mermaid-svg-O4FZnxZvbM5x5neh .rough-node .label,#mermaid-svg-O4FZnxZvbM5x5neh .node .label,#mermaid-svg-O4FZnxZvbM5x5neh .image-shape .label,#mermaid-svg-O4FZnxZvbM5x5neh .icon-shape .label{text-align:center;}#mermaid-svg-O4FZnxZvbM5x5neh .node.clickable{cursor:pointer;}#mermaid-svg-O4FZnxZvbM5x5neh .root .anchor path{fill:#333333!important;stroke-width:0;stroke:#333333;}#mermaid-svg-O4FZnxZvbM5x5neh .arrowheadPath{fill:#333333;}#mermaid-svg-O4FZnxZvbM5x5neh .edgePath .path{stroke:#333333;stroke-width:2.0px;}#mermaid-svg-O4FZnxZvbM5x5neh .flowchart-link{stroke:#333333;fill:none;}#mermaid-svg-O4FZnxZvbM5x5neh .edgeLabel{background-color:rgba(232,232,232, 0.8);text-align:center;}#mermaid-svg-O4FZnxZvbM5x5neh .edgeLabel p{background-color:rgba(232,232,232, 0.8);}#mermaid-svg-O4FZnxZvbM5x5neh .edgeLabel rect{opacity:0.5;background-color:rgba(232,232,232, 0.8);fill:rgba(232,232,232, 0.8);}#mermaid-svg-O4FZnxZvbM5x5neh .labelBkg{background-color:rgba(232, 232, 232, 0.5);}#mermaid-svg-O4FZnxZvbM5x5neh .cluster rect{fill:#ffffde;stroke:#aaaa33;stroke-width:1px;}#mermaid-svg-O4FZnxZvbM5x5neh .cluster text{fill:#333;}#mermaid-svg-O4FZnxZvbM5x5neh .cluster span{color:#333;}#mermaid-svg-O4FZnxZvbM5x5neh div.mermaidTooltip{position:absolute;text-align:center;max-width:200px;padding:2px;font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:12px;background:hsl(80, 100%, 96.2745098039%);border:1px solid #aaaa33;border-radius:2px;pointer-events:none;z-index:100;}#mermaid-svg-O4FZnxZvbM5x5neh .flowchartTitleText{text-anchor:middle;font-size:18px;fill:#333;}#mermaid-svg-O4FZnxZvbM5x5neh rect.text{fill:none;stroke-width:0;}#mermaid-svg-O4FZnxZvbM5x5neh .icon-shape,#mermaid-svg-O4FZnxZvbM5x5neh .image-shape{background-color:rgba(232,232,232, 0.8);text-align:center;}#mermaid-svg-O4FZnxZvbM5x5neh .icon-shape p,#mermaid-svg-O4FZnxZvbM5x5neh .image-shape p{background-color:rgba(232,232,232, 0.8);padding:2px;}#mermaid-svg-O4FZnxZvbM5x5neh .icon-shape rect,#mermaid-svg-O4FZnxZvbM5x5neh .image-shape rect{opacity:0.5;background-color:rgba(232,232,232, 0.8);fill:rgba(232,232,232, 0.8);}#mermaid-svg-O4FZnxZvbM5x5neh .label-icon{display:inline-block;height:1em;overflow:visible;vertical-align:-0.125em;}#mermaid-svg-O4FZnxZvbM5x5neh .node .label-icon path{fill:currentColor;stroke:revert;stroke-width:revert;}#mermaid-svg-O4FZnxZvbM5x5neh :root{–mermaid-font-family:\”trebuchet ms\”,verdana,arial,sans-serif;}

否

是

否

是

是

否

用户请求

Security Filter Chain

已认证?

认证过滤器

登录验证

成功?

创建SecurityContext

返回401

有权限?

访问资源

返回403

3.2 过滤器链结构

#mermaid-svg-BLyXhcFtbs9G2wxx{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;fill:#333;}@keyframes edge-animation-frame{from{stroke-dashoffset:0;}}@keyframes dash{to{stroke-dashoffset:0;}}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-animation-slow{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 50s linear infinite;stroke-linecap:round;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-animation-fast{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 20s linear infinite;stroke-linecap:round;}#mermaid-svg-BLyXhcFtbs9G2wxx .error-icon{fill:#552222;}#mermaid-svg-BLyXhcFtbs9G2wxx .error-text{fill:#552222;stroke:#552222;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-thickness-normal{stroke-width:1px;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-thickness-thick{stroke-width:3.5px;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-pattern-solid{stroke-dasharray:0;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-thickness-invisible{stroke-width:0;fill:none;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-pattern-dashed{stroke-dasharray:3;}#mermaid-svg-BLyXhcFtbs9G2wxx .edge-pattern-dotted{stroke-dasharray:2;}#mermaid-svg-BLyXhcFtbs9G2wxx .marker{fill:#333333;stroke:#333333;}#mermaid-svg-BLyXhcFtbs9G2wxx .marker.cross{stroke:#333333;}#mermaid-svg-BLyXhcFtbs9G2wxx svg{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;}#mermaid-svg-BLyXhcFtbs9G2wxx p{margin:0;}#mermaid-svg-BLyXhcFtbs9G2wxx .label{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;color:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx .cluster-label text{fill:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx .cluster-label span{color:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx .cluster-label span p{background-color:transparent;}#mermaid-svg-BLyXhcFtbs9G2wxx .label text,#mermaid-svg-BLyXhcFtbs9G2wxx span{fill:#333;color:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx .node rect,#mermaid-svg-BLyXhcFtbs9G2wxx .node circle,#mermaid-svg-BLyXhcFtbs9G2wxx .node ellipse,#mermaid-svg-BLyXhcFtbs9G2wxx .node polygon,#mermaid-svg-BLyXhcFtbs9G2wxx .node path{fill:#ECECFF;stroke:#9370DB;stroke-width:1px;}#mermaid-svg-BLyXhcFtbs9G2wxx .rough-node .label text,#mermaid-svg-BLyXhcFtbs9G2wxx .node .label text,#mermaid-svg-BLyXhcFtbs9G2wxx .image-shape .label,#mermaid-svg-BLyXhcFtbs9G2wxx .icon-shape .label{text-anchor:middle;}#mermaid-svg-BLyXhcFtbs9G2wxx .node .katex path{fill:#000;stroke:#000;stroke-width:1px;}#mermaid-svg-BLyXhcFtbs9G2wxx .rough-node .label,#mermaid-svg-BLyXhcFtbs9G2wxx .node .label,#mermaid-svg-BLyXhcFtbs9G2wxx .image-shape .label,#mermaid-svg-BLyXhcFtbs9G2wxx .icon-shape .label{text-align:center;}#mermaid-svg-BLyXhcFtbs9G2wxx .node.clickable{cursor:pointer;}#mermaid-svg-BLyXhcFtbs9G2wxx .root .anchor path{fill:#333333!important;stroke-width:0;stroke:#333333;}#mermaid-svg-BLyXhcFtbs9G2wxx .arrowheadPath{fill:#333333;}#mermaid-svg-BLyXhcFtbs9G2wxx .edgePath .path{stroke:#333333;stroke-width:2.0px;}#mermaid-svg-BLyXhcFtbs9G2wxx .flowchart-link{stroke:#333333;fill:none;}#mermaid-svg-BLyXhcFtbs9G2wxx .edgeLabel{background-color:rgba(232,232,232, 0.8);text-align:center;}#mermaid-svg-BLyXhcFtbs9G2wxx .edgeLabel p{background-color:rgba(232,232,232, 0.8);}#mermaid-svg-BLyXhcFtbs9G2wxx .edgeLabel rect{opacity:0.5;background-color:rgba(232,232,232, 0.8);fill:rgba(232,232,232, 0.8);}#mermaid-svg-BLyXhcFtbs9G2wxx .labelBkg{background-color:rgba(232, 232, 232, 0.5);}#mermaid-svg-BLyXhcFtbs9G2wxx .cluster rect{fill:#ffffde;stroke:#aaaa33;stroke-width:1px;}#mermaid-svg-BLyXhcFtbs9G2wxx .cluster text{fill:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx .cluster span{color:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx div.mermaidTooltip{position:absolute;text-align:center;max-width:200px;padding:2px;font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:12px;background:hsl(80, 100%, 96.2745098039%);border:1px solid #aaaa33;border-radius:2px;pointer-events:none;z-index:100;}#mermaid-svg-BLyXhcFtbs9G2wxx .flowchartTitleText{text-anchor:middle;font-size:18px;fill:#333;}#mermaid-svg-BLyXhcFtbs9G2wxx rect.text{fill:none;stroke-width:0;}#mermaid-svg-BLyXhcFtbs9G2wxx .icon-shape,#mermaid-svg-BLyXhcFtbs9G2wxx .image-shape{background-color:rgba(232,232,232, 0.8);text-align:center;}#mermaid-svg-BLyXhcFtbs9G2wxx .icon-shape p,#mermaid-svg-BLyXhcFtbs9G2wxx .image-shape p{background-color:rgba(232,232,232, 0.8);padding:2px;}#mermaid-svg-BLyXhcFtbs9G2wxx .icon-shape rect,#mermaid-svg-BLyXhcFtbs9G2wxx .image-shape rect{opacity:0.5;background-color:rgba(232,232,232, 0.8);fill:rgba(232,232,232, 0.8);}#mermaid-svg-BLyXhcFtbs9G2wxx .label-icon{display:inline-block;height:1em;overflow:visible;vertical-align:-0.125em;}#mermaid-svg-BLyXhcFtbs9G2wxx .node .label-icon path{fill:currentColor;stroke:revert;stroke-width:revert;}#mermaid-svg-BLyXhcFtbs9G2wxx :root{–mermaid-font-family:\”trebuchet ms\”,verdana,arial,sans-serif;}

请求

ChannelProcessingFilter

SecurityContextFilter

LogoutFilter

UsernamePasswordAuthenticationFilter

ExceptionTranslationFilter

FilterSecurityInterceptor

Controller

四、快速开始

4.1 添加依赖

<!– pom.xml –>
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-security</artifactId>
</dependency>

4.2 基础配置

@Configuration
@EnableWebSecurity
public class SecurityConfig {

@Bean
public SecurityFilterChain filterChain(HttpSecurity http) throws Exception {
http
.authorizeHttpRequests(auth -> auth
.requestMatchers("/public/**").permitAll()
.anyRequest().authenticated()
)
.formLogin(withDefaults())
.httpBasic(withDefaults());
return http.build();
}
}

五、认证机制详解

5.1 内存认证（开发测试）

@Bean
public UserDetailsService userDetailsService() {
UserDetails user = User.builder()
.username("admin")
.password(passwordEncoder().encode("123456"))
.roles("ADMIN")
.build();

UserDetails guest = User.builder()
.username("guest")
.password(passwordEncoder().encode("123456"))
.roles("GUEST")
.build();

return new InMemoryUserDetailsManager(user, guest);
}

@Bean
public PasswordEncoder passwordEncoder() {
return new BCryptPasswordEncoder();
}

5.2 数据库认证（生产推荐）

@Service
public class CustomUserDetailsService implements UserDetailsService {

@Autowired
private UserRepository userRepository;

@Override
public UserDetails loadUserByUsername(String username) {
User user = userRepository.findByUsername(username)
.orElseThrow(() -> new UsernameNotFoundException("用户不存在"));

return User.withUsername(user.getUsername())
.password(user.getPassword())
.roles(user.getRole())
.build();
}
}

六、授权控制方式

6.1 注解方式

// 启用注解
@EnableGlobalMethodSecurity(prePostEnabled = true)

// 使用示例
@Service
public class UserService {

@PreAuthorize("hasRole('ADMIN')")
public void deleteUser(Long id) {
// 只有ADMIN角色可以删除
}

@PreAuthorize("#userId == authentication.principal.id")
public User getUserInfo(Long userId) {
// 只能查询自己的信息
}

@PostFilter("filterObject.owner == authentication.name")
public List<Document> getAllDocuments() {
// 过滤返回结果
}
}

6.2 配置方式

@Bean
public SecurityFilterChain filterChain(HttpSecurity http) throws Exception {
http
.authorizeHttpRequests(auth -> auth
.requestMatchers("/api/admin/**").hasRole("ADMIN")
.requestMatchers("/api/user/**").hasAnyRole("ADMIN", "USER")
.requestMatchers(HttpMethod.POST, "/api/posts").hasAuthority("post:write")
.requestMatchers("/public/**").permitAll()
.anyRequest().authenticated()
);
return http.build();
}

七、JWT 无状态认证

7.1 JWT 认证流程

资源

服务器

用户

资源

服务器

用户

#mermaid-svg-bdTHXWwInETfZOrb{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;fill:#333;}@keyframes edge-animation-frame{from{stroke-dashoffset:0;}}@keyframes dash{to{stroke-dashoffset:0;}}#mermaid-svg-bdTHXWwInETfZOrb .edge-animation-slow{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 50s linear infinite;stroke-linecap:round;}#mermaid-svg-bdTHXWwInETfZOrb .edge-animation-fast{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 20s linear infinite;stroke-linecap:round;}#mermaid-svg-bdTHXWwInETfZOrb .error-icon{fill:#552222;}#mermaid-svg-bdTHXWwInETfZOrb .error-text{fill:#552222;stroke:#552222;}#mermaid-svg-bdTHXWwInETfZOrb .edge-thickness-normal{stroke-width:1px;}#mermaid-svg-bdTHXWwInETfZOrb .edge-thickness-thick{stroke-width:3.5px;}#mermaid-svg-bdTHXWwInETfZOrb .edge-pattern-solid{stroke-dasharray:0;}#mermaid-svg-bdTHXWwInETfZOrb .edge-thickness-invisible{stroke-width:0;fill:none;}#mermaid-svg-bdTHXWwInETfZOrb .edge-pattern-dashed{stroke-dasharray:3;}#mermaid-svg-bdTHXWwInETfZOrb .edge-pattern-dotted{stroke-dasharray:2;}#mermaid-svg-bdTHXWwInETfZOrb .marker{fill:#333333;stroke:#333333;}#mermaid-svg-bdTHXWwInETfZOrb .marker.cross{stroke:#333333;}#mermaid-svg-bdTHXWwInETfZOrb svg{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;}#mermaid-svg-bdTHXWwInETfZOrb p{margin:0;}#mermaid-svg-bdTHXWwInETfZOrb .actor{stroke:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);fill:#ECECFF;}#mermaid-svg-bdTHXWwInETfZOrb text.actor>tspan{fill:black;stroke:none;}#mermaid-svg-bdTHXWwInETfZOrb .actor-line{stroke:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);}#mermaid-svg-bdTHXWwInETfZOrb .innerArc{stroke-width:1.5;stroke-dasharray:none;}#mermaid-svg-bdTHXWwInETfZOrb .messageLine0{stroke-width:1.5;stroke-dasharray:none;stroke:#333;}#mermaid-svg-bdTHXWwInETfZOrb .messageLine1{stroke-width:1.5;stroke-dasharray:2,2;stroke:#333;}#mermaid-svg-bdTHXWwInETfZOrb #arrowhead path{fill:#333;stroke:#333;}#mermaid-svg-bdTHXWwInETfZOrb .sequenceNumber{fill:white;}#mermaid-svg-bdTHXWwInETfZOrb #sequencenumber{fill:#333;}#mermaid-svg-bdTHXWwInETfZOrb #crosshead path{fill:#333;stroke:#333;}#mermaid-svg-bdTHXWwInETfZOrb .messageText{fill:#333;stroke:none;}#mermaid-svg-bdTHXWwInETfZOrb .labelBox{stroke:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);fill:#ECECFF;}#mermaid-svg-bdTHXWwInETfZOrb .labelText,#mermaid-svg-bdTHXWwInETfZOrb .labelText>tspan{fill:black;stroke:none;}#mermaid-svg-bdTHXWwInETfZOrb .loopText,#mermaid-svg-bdTHXWwInETfZOrb .loopText>tspan{fill:black;stroke:none;}#mermaid-svg-bdTHXWwInETfZOrb .loopLine{stroke-width:2px;stroke-dasharray:2,2;stroke:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);fill:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);}#mermaid-svg-bdTHXWwInETfZOrb .note{stroke:#aaaa33;fill:#fff5ad;}#mermaid-svg-bdTHXWwInETfZOrb .noteText,#mermaid-svg-bdTHXWwInETfZOrb .noteText>tspan{fill:black;stroke:none;}#mermaid-svg-bdTHXWwInETfZOrb .activation0{fill:#f4f4f4;stroke:#666;}#mermaid-svg-bdTHXWwInETfZOrb .activation1{fill:#f4f4f4;stroke:#666;}#mermaid-svg-bdTHXWwInETfZOrb .activation2{fill:#f4f4f4;stroke:#666;}#mermaid-svg-bdTHXWwInETfZOrb .actorPopupMenu{position:absolute;}#mermaid-svg-bdTHXWwInETfZOrb .actorPopupMenuPanel{position:absolute;fill:#ECECFF;box-shadow:0px 8px 16px 0px rgba(0,0,0,0.2);filter:drop-shadow(3px 5px 2px rgb(0 0 0 / 0.4));}#mermaid-svg-bdTHXWwInETfZOrb .actor-man line{stroke:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);fill:#ECECFF;}#mermaid-svg-bdTHXWwInETfZOrb .actor-man circle,#mermaid-svg-bdTHXWwInETfZOrb line{stroke:hsl(259.6261682243, 59.7765363128%, 87.9019607843%);fill:#ECECFF;stroke-width:2px;}#mermaid-svg-bdTHXWwInETfZOrb :root{–mermaid-font-family:\”trebuchet ms\”,verdana,arial,sans-serif;}

POST /login {username, password}

验证用户信息

返回JWT Token

GET /api/data (Header: Authorization: Bearer <token>)

验证Token

返回数据

7.2 JWT 实现

// JWT 工具类
@Component
public class JwtUtil {

@Value("${jwt.secret}")
private String secret;

public String generateToken(UserDetails userDetails) {
return Jwts.builder()
.setSubject(userDetails.getUsername())
.setIssuedAt(new Date())
.setExpiration(new Date(System.currentTimeMillis() + 86400000))
.signWith(SignatureAlgorithm.HS256, secret)
.compact();
}

public boolean validateToken(String token, UserDetails userDetails) {
return extractUsername(token).equals(userDetails.getUsername())
&& !isTokenExpired(token);
}
}

// JWT 认证过滤器
public class JwtAuthenticationFilter extends OncePerRequestFilter {

@Override
protected void doFilterInternal(HttpServletRequest request,
HttpServletResponse response,
FilterChain chain) {
String token = extractToken(request);
if (token != null && jwtUtil.validateToken(token, userDetails)) {
UsernamePasswordAuthenticationToken auth =
new UsernamePasswordAuthenticationToken(userDetails, null, userDetails.getAuthorities());
SecurityContextHolder.getContext().setAuthentication(auth);
}
chain.doFilter(request, response);
}
}

八、常见场景解决方案

8.1 场景一：记住我功能

http
.rememberMe(remember -> remember
.key("unique-and-secret")
.tokenValiditySeconds(86400)
.userDetailsService(userDetailsService)
);

8.2 场景二：退出登录

http
.logout(logout -> logout
.logoutUrl("/logout")
.logoutSuccessUrl("/login?logout")
.deleteCookies("JSESSIONID")
.addLogoutHandler(new SecurityContextLogoutHandler())
);

8.3 场景三：CSRF 防护

http
.csrf(csrf -> csrf
.csrfTokenRepository(CookieCsrfTokenRepository.withHttpOnlyFalse())
// API接口可以禁用CSRF
.ignoringRequestMatchers("/api/**")
);

8.4 场景四：自定义登录页

http
.formLogin(form -> form
.loginPage("/login")
.defaultSuccessUrl("/dashboard")
.permitAll()
);

九、学习路线

#mermaid-svg-IxqcqUHT2aSVDiCU{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;fill:#333;}@keyframes edge-animation-frame{from{stroke-dashoffset:0;}}@keyframes dash{to{stroke-dashoffset:0;}}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-animation-slow{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 50s linear infinite;stroke-linecap:round;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-animation-fast{stroke-dasharray:9,5!important;stroke-dashoffset:900;animation:dash 20s linear infinite;stroke-linecap:round;}#mermaid-svg-IxqcqUHT2aSVDiCU .error-icon{fill:#552222;}#mermaid-svg-IxqcqUHT2aSVDiCU .error-text{fill:#552222;stroke:#552222;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-thickness-normal{stroke-width:1px;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-thickness-thick{stroke-width:3.5px;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-pattern-solid{stroke-dasharray:0;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-thickness-invisible{stroke-width:0;fill:none;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-pattern-dashed{stroke-dasharray:3;}#mermaid-svg-IxqcqUHT2aSVDiCU .edge-pattern-dotted{stroke-dasharray:2;}#mermaid-svg-IxqcqUHT2aSVDiCU .marker{fill:#333333;stroke:#333333;}#mermaid-svg-IxqcqUHT2aSVDiCU .marker.cross{stroke:#333333;}#mermaid-svg-IxqcqUHT2aSVDiCU svg{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:16px;}#mermaid-svg-IxqcqUHT2aSVDiCU p{margin:0;}#mermaid-svg-IxqcqUHT2aSVDiCU .label{font-family:\”trebuchet ms\”,verdana,arial,sans-serif;color:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU .cluster-label text{fill:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU .cluster-label span{color:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU .cluster-label span p{background-color:transparent;}#mermaid-svg-IxqcqUHT2aSVDiCU .label text,#mermaid-svg-IxqcqUHT2aSVDiCU span{fill:#333;color:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU .node rect,#mermaid-svg-IxqcqUHT2aSVDiCU .node circle,#mermaid-svg-IxqcqUHT2aSVDiCU .node ellipse,#mermaid-svg-IxqcqUHT2aSVDiCU .node polygon,#mermaid-svg-IxqcqUHT2aSVDiCU .node path{fill:#ECECFF;stroke:#9370DB;stroke-width:1px;}#mermaid-svg-IxqcqUHT2aSVDiCU .rough-node .label text,#mermaid-svg-IxqcqUHT2aSVDiCU .node .label text,#mermaid-svg-IxqcqUHT2aSVDiCU .image-shape .label,#mermaid-svg-IxqcqUHT2aSVDiCU .icon-shape .label{text-anchor:middle;}#mermaid-svg-IxqcqUHT2aSVDiCU .node .katex path{fill:#000;stroke:#000;stroke-width:1px;}#mermaid-svg-IxqcqUHT2aSVDiCU .rough-node .label,#mermaid-svg-IxqcqUHT2aSVDiCU .node .label,#mermaid-svg-IxqcqUHT2aSVDiCU .image-shape .label,#mermaid-svg-IxqcqUHT2aSVDiCU .icon-shape .label{text-align:center;}#mermaid-svg-IxqcqUHT2aSVDiCU .node.clickable{cursor:pointer;}#mermaid-svg-IxqcqUHT2aSVDiCU .root .anchor path{fill:#333333!important;stroke-width:0;stroke:#333333;}#mermaid-svg-IxqcqUHT2aSVDiCU .arrowheadPath{fill:#333333;}#mermaid-svg-IxqcqUHT2aSVDiCU .edgePath .path{stroke:#333333;stroke-width:2.0px;}#mermaid-svg-IxqcqUHT2aSVDiCU .flowchart-link{stroke:#333333;fill:none;}#mermaid-svg-IxqcqUHT2aSVDiCU .edgeLabel{background-color:rgba(232,232,232, 0.8);text-align:center;}#mermaid-svg-IxqcqUHT2aSVDiCU .edgeLabel p{background-color:rgba(232,232,232, 0.8);}#mermaid-svg-IxqcqUHT2aSVDiCU .edgeLabel rect{opacity:0.5;background-color:rgba(232,232,232, 0.8);fill:rgba(232,232,232, 0.8);}#mermaid-svg-IxqcqUHT2aSVDiCU .labelBkg{background-color:rgba(232, 232, 232, 0.5);}#mermaid-svg-IxqcqUHT2aSVDiCU .cluster rect{fill:#ffffde;stroke:#aaaa33;stroke-width:1px;}#mermaid-svg-IxqcqUHT2aSVDiCU .cluster text{fill:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU .cluster span{color:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU div.mermaidTooltip{position:absolute;text-align:center;max-width:200px;padding:2px;font-family:\”trebuchet ms\”,verdana,arial,sans-serif;font-size:12px;background:hsl(80, 100%, 96.2745098039%);border:1px solid #aaaa33;border-radius:2px;pointer-events:none;z-index:100;}#mermaid-svg-IxqcqUHT2aSVDiCU .flowchartTitleText{text-anchor:middle;font-size:18px;fill:#333;}#mermaid-svg-IxqcqUHT2aSVDiCU rect.text{fill:none;stroke-width:0;}#mermaid-svg-IxqcqUHT2aSVDiCU .icon-shape,#mermaid-svg-IxqcqUHT2aSVDiCU .image-shape{background-color:rgba(232,232,232, 0.8);text-align:center;}#mermaid-svg-IxqcqUHT2aSVDiCU .icon-shape p,#mermaid-svg-IxqcqUHT2aSVDiCU .image-shape p{background-color:rgba(232,232,232, 0.8);padding:2px;}#mermaid-svg-IxqcqUHT2aSVDiCU .icon-shape rect,#mermaid-svg-IxqcqUHT2aSVDiCU .image-shape rect{opacity:0.5;background-color:rgba(232,232,232, 0.8);fill:rgba(232,232,232, 0.8);}#mermaid-svg-IxqcqUHT2aSVDiCU .label-icon{display:inline-block;height:1em;overflow:visible;vertical-align:-0.125em;}#mermaid-svg-IxqcqUHT2aSVDiCU .node .label-icon path{fill:currentColor;stroke:revert;stroke-width:revert;}#mermaid-svg-IxqcqUHT2aSVDiCU :root{–mermaid-font-family:\”trebuchet ms\”,verdana,arial,sans-serif;}

Spring Security 入门

理解核心概念

认证机制

授权控制

JWT集成

OAuth2/SAML

微服务安全

实战项目

9.1 学习时间建议

十、最佳实践

10.1 密码加密

// 始终使用 BCrypt
@Bean
public PasswordEncoder passwordEncoder() {
return new BCryptPasswordEncoder();
}

10.2 权限设计原则

// 推荐：基于角色的权限访问控制 (RBAC)
@PreAuthorize("hasRole('ADMIN') and hasAuthority('user:delete')")

// 不推荐：硬编码
@PreAuthorize("hasRole('ADMIN') or username == 'admin'")

10.3 异常处理

@RestControllerAdvice
public class SecurityExceptionHandler {

@ExceptionHandler(AccessDeniedException.class)
public ResponseEntity<?> handleAccessDenied(AccessDeniedException e) {
return ResponseEntity.status(403)
.body("没有权限访问该资源");
}
}

10.4 安全配置

// 生产环境必须配置
http
.headers(headers -> headers
.contentSecurityPolicy(csp -> csp.policyDirectives("default-src 'self'"))
.frameOptions(frame -> frame.sameOrigin())
.httpStrictTransportSecurity(hsts -> hsts
.includeSubDomains(true)
.maxAgeInSeconds(31536000)
)
);

十一、总结

Spring Security 虽然学习曲线陡峭，但一旦掌握，将极大提升应用的安全性和开发效率。

11.1核心要点回顾

十二、推荐资源

💡 一句话总结：Spring Security 是企业级 Java 应用的安全基石，值得深入学习和掌握！
