1 ~> UDP编程：三个代码案例搞定

很多人学UDP编程只停留在"能发能收"的Echo服务器阶段，但真实的网络服务需要解决多用户并发、业务解耦、性能瓶颈、跨平台兼容四大核心问题。本文将带你走完UDP编程的完整学习路线：

本文所有代码均基于C++17标准，兼容Linux与Windows平台，所有代码均来自真实生产实践，可直接编译运行，如果有问题，简单调试，通过修改参数、调整文件名、检查构造函数初始化顺序等方式可以矫正。

2 ~> 先搞透基础：UDP Socket核心原理全景

2.1 Socket的本质：操作系统提供的网络抽象

• 定义：Socket是应用层与TCP/IP协议栈之间的编程接口，本质是一个特殊的文件描述符

• 类比：Socket = 网络电话，IP = 手机号，端口 = 分机号

• 核心特性：UDP是无连接、不可靠、面向数据报的协议，支持全双工通信

2.2 核心数据结构：sockaddr_in与地址转换

// IPv4地址结构体
struct sockaddr_in {
short int sin_family; // 地址族，固定为AF_INET
unsigned short int sin_port; // 16位端口号（网络字节序）
struct in_addr sin_addr; // 32位IP地址（网络字节序）
unsigned char sin_zero[8]; // 填充字节
};

2.2.1 地址转换函数

坑人点：inet_ntoa()使用静态缓冲区存储结果，多线程调用会互相覆盖，生产环境必须使用inet_ntop()。

2.3 字节序：为什么必须处理大小端？

• 大端序：高位字节存低地址，网络字节序统一使用大端

• 小端序：低位字节存低地址，x86/x86_64架构CPU默认使用小端

• 核心转换函数：

  • htons()：主机序 → 网络序（短整型，用于端口）

  • ntohs()：网络序 → 主机序（短整型）

  • htonl()/ntohl()：长整型转换（用于IP地址）

2.4 bind函数深度解析

• 作用：将Socket与指定的IP和端口绑定，告诉操作系统"这个Socket负责接收发往该地址的数据包"

• 为什么服务器必须显式bind？：服务器端口必须是固定且众所周知的，客户端才能连接

• 为什么推荐绑定 0.0.0.0 ？：

  • 0.0.0.0表示监听本机所有网卡的所有IP地址

  • 云服务器网卡上没有配置公网IP（公网IP是运营商NAT映射的），直接绑定公网IP会失败

• 常见bind失败原因：端口被占用、权限不足（1024以下端口需要root）、绑定不存在的IP

2.5 客户端为什么不需要显式bind？

• 客户端调用sendto()时，操作系统会自动为其分配一个随机的未被占用的端口

• 客户端数量众多，不需要固定端口，自动分配可以避免端口冲突

3 ~> V1版本：Echo回显服务器

3.1 完整代码实现

3.1.1 Mutex.hpp（互斥锁封装）

#ifndef __MUTEX_HPP
#define __MUTEX_HPP

#include <pthread.h>

class Mutex
{
public:
Mutex()
{
pthread_mutex_init(&_lock, nullptr);
}
void Lock()
{
pthread_mutex_lock(&_lock);
}
pthread_mutex_t *Orgin()
{
return &_lock;
}
void Unlock()
{
pthread_mutex_unlock(&_lock);
}
~Mutex()
{
pthread_mutex_destroy(&_lock);
}
private:
pthread_mutex_t _lock;
};

// 自动加解锁的Guard（RAII风格）
class LockGuard
{
public:
LockGuard(Mutex *lockp): _lockp(lockp)
{
_lockp->Lock();
}
~LockGuard()
{
_lockp->Unlock();
}
private:
Mutex *_lockp;
};

#endif

3.1.2 Logger.hpp（日志模块）

#ifndef __LOGGER_HPP
#define __LOGGER_HPP

#include <iostream>
#include <cstdio>
#include <string>
#include <ctime>
#include <filesystem>
#include <fstream>
#include <sstream>
#include <memory>
#include <unistd.h>
#include <cstdlib>
#include "Mutex.hpp"

namespace LogModule
{
std::string GetTimeStamp()
{
time_t timestamp = time(nullptr);
struct tm data_time;
localtime_r(&timestamp, &data_time);

char data_time_str[128];
snprintf(data_time_str, sizeof(data_time_str), "%4d-%02d-%02d %02d:%02d:%02d",
data_time.tm_year + 1900,
data_time.tm_mon + 1,
data_time.tm_mday,
data_time.tm_hour,
data_time.tm_min,
data_time.tm_sec);

return data_time_str;
}

enum class LogLevel
{
DEBUG,
INFO,
WARNING,
ERROR,
FATAL
};

std::string LogLevel2String(LogLevel level)
{
switch (level)
{
case LogLevel::DEBUG: return "DEBUG";
case LogLevel::INFO: return "INFO";
case LogLevel::WARNING: return "WARNING";
case LogLevel::ERROR: return "ERROR";
case LogLevel::FATAL: return "FATAL";
default: return "UNKNOWN";
}
}

class LogStrategy
{
public:
virtual ~LogStrategy() = default;
virtual void SyncLog(const std::string &logmessage) = 0;
};

class ConsoleLogStrategy : public LogStrategy
{
public:
void SyncLog(const std::string &logmessage) override
{
LockGuard lockguard(&_mutex);
std::cout << logmessage << std::endl;
}

private:
Mutex _mutex;
};

static const std::string glogdir = "./log/";
static const std::string glogfilename = "log.txt";
class FileLogStrategy : public LogStrategy
{
public:
FileLogStrategy(const std::string &dir = glogdir, const std::string &filename = glogfilename)
: _logdir(dir), _logfilename(filename)
{
LockGuard lockguard(&_mutex);
if (!std::filesystem::exists(_logdir))
{
try
{
std::filesystem::create_directories(_logdir);
}
catch (const std::filesystem::filesystem_error &e)
{
std::cerr << "创建日志目录失败: " << e.what() << '\\n';
}
}
}

void SyncLog(const std::string &logmessage) override
{
LockGuard lockguard(&_mutex);
std::string target = _logdir + _logfilename;
std::ofstream out(target, std::ios::app);
if (!out.is_open())
{
std::cerr << "打开日志文件失败: " << target << std::endl;
return;
}
out << logmessage << "\\n";
out.close();
}

private:
std::string _logdir;
std::string _logfilename;
Mutex _mutex;
};

class Logger
{
public:
Logger()
{
UseConsoleLogStrategy();
}

void UseConsoleLogStrategy()
{
_strategy = std::make_unique<ConsoleLogStrategy>();
}

void UseFileLogStrategy()
{
_strategy = std::make_unique<FileLogStrategy>();
}

class LogMessage
{
public:
LogMessage(LogLevel level, std::string filename, int line, Logger &self)
: _level(level),
_curr_time(GetTimeStamp()),
_pid(getpid()),
_filename(std::move(filename)),
_line(line),
_logger(self)
{
std::stringstream ss;
ss << "[" << _curr_time << "] "
<< "[" << LogLevel2String(_level) << "] "
<< "[" << _pid << "] "
<< "[" << _filename << ":" << _line << "] "
<< "- ";
_loginfo = ss.str();
}

template <typename T>
LogMessage &operator<<(const T &info)
{
std::stringstream ss;
ss << info;
_loginfo += ss.str();
return *this;
}

~LogMessage()
{
if (_logger._strategy)
{
_logger._strategy->SyncLog(_loginfo);
}
if (_level == LogLevel::FATAL)
{
exit(EXIT_FAILURE);
}
}

private:
LogLevel _level;
std::string _curr_time;
pid_t _pid;
std::string _filename;
int _line;
std::string _loginfo;
Logger &_logger;
};

LogMessage operator()(LogLevel level, std::string filename, int line)
{
return LogMessage(level, std::move(filename), line, *this);
}

private:
std::unique_ptr<LogStrategy> _strategy;
};

Logger logger;

#define LOG(level) logger(level, __FILE__, __LINE__)
#define ENABLE_CONSOLE_LOG() logger.UseConsoleLogStrategy()
#define ENABLE_FILE_LOG() logger.UseFileLogStrategy()
}

#endif

3.1.3 UdpEchoServer.hpp（核心逻辑）

#ifndef __UDP_ECHOSERVER_HPP
#define __UDP_ECHOSERVER_HPP

#include <iostream>
#include <string>
#include <cstring>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <cstdlib>
#include "Logger.hpp"

using namespace LogModule;

class UdpEchoServer
{
public:
UdpEchoServer(uint16_t port)
: _sockfd(–1), _port(port)
{
}

void Init()
{
_sockfd = socket(AF_INET, SOCK_DGRAM, 0);
if (_sockfd < 0)
{
LOG(LogLevel::FATAL) << "创建Socket失败！";
exit(EXIT_FAILURE);
}
LOG(LogLevel::INFO) << "创建Socket成功，fd: " << _sockfd;

struct sockaddr_in local;
std::memset(&local, 0, sizeof(local));
local.sin_family = AF_INET;
local.sin_port = htons(_port);
local.sin_addr.s_addr = INADDR_ANY;

if (bind(_sockfd, (struct sockaddr *)&local, sizeof(local)) < 0)
{
LOG(LogLevel::FATAL) << "绑定端口[" << _port << "]失败！";
exit(EXIT_FAILURE);
}
LOG(LogLevel::INFO) << "绑定端口[" << _port << "]成功！";
}

void Start()
{
LOG(LogLevel::INFO) << "UDP Echo Server 启动成功，监听端口: " << _port;

char buffer[1024] = {0};
struct sockaddr_in peer;
socklen_t peer_len = sizeof(peer);

while (true)
{
ssize_t n = recvfrom(_sockfd, buffer, sizeof(buffer)–1, 0,
(struct sockaddr *)&peer, &peer_len);
if (n < 0)
{
LOG(LogLevel::WARNING) << "接收数据失败！";
continue;
}

buffer[n] = '\\0';
std::string client_ip = inet_ntoa(peer.sin_addr);
uint16_t client_port = ntohs(peer.sin_port);

LOG(LogLevel::INFO) << "收到客户端[" << client_ip << ":" << client_port
<< "]消息: " << buffer;

std::string echo_msg = "[Echo] " + std::string(buffer);

sendto(_sockfd, echo_msg.c_str(), echo_msg.size(), 0,
(struct sockaddr *)&peer, peer_len);
}
}

~UdpEchoServer()
{
if (_sockfd >= 0)
{
close(_sockfd);
LOG(LogLevel::INFO) << "关闭Socket，fd: " << _sockfd;
}
}

private:
int _sockfd;
uint16_t _port;
};

#endif

3.1.4 main.cpp（程序入口）

#include "UdpEchoServer.hpp"
#include <iostream>

void Usage(const char *progname)
{
std::cout << "Usage: " << progname << " <port>" << std::endl;
std::cout << "Example: " << progname << " 8080" << std::endl;
}

int main(int argc, char *argv[])
{
if (argc != 2)
{
Usage(argv[0]);
return EXIT_FAILURE;
}

uint16_t port = atoi(argv[1]);
if (port <= 1024 || port > 65535)
{
std::cerr << "端口必须在 1025~65535 之间！" << std::endl;
return EXIT_FAILURE;
}

// ENABLE_FILE_LOG(); // 可选：切换到文件日志

UdpEchoServer server(port);
server.Init();
server.Start();

return EXIT_SUCCESS;
}

3.2 编译与运行

3.2.1 Makefile

CC = g++
STD = -std=c++17
CFLAGS = -Wall -g -lpthread

all: udp_echo_server

udp_echo_server: main.cpp
$(CC) -o $@ $^ $(STD) $(CFLAGS)

.PHONY: clean
clean:
rm -f udp_echo_server
rm -rf log/

3.2.2 运行命令

make
./udp_echo_server 8080

3.2.3 客户端测试

nc -u 127.0.0.1 8080
# 输入任意字符，会收到服务器回显

3.3 V1版本的局限性

• 网络层与业务逻辑强耦合，无法复用

• 只能处理单客户端，不支持多用户

• 基础日志，无生产级错误处理

• 单线程模型，性能瓶颈明显

4 ~> V2版本：增强版英译汉字典服务器（生产级解耦）

4.1 核心改进：生产级工程化能力

相比基础版字典服务器，本版本增加了：

• 策略模式日志系统：支持控制台/文件双日志输出，线程安全

• 配置文件加载：从外部txt文件加载字典数据，支持动态扩展

• 完善的错误处理：文件打开失败、格式错误等异常处理

• 增强字典内容：每个单词包含中文翻译+英文例句+中文例句

4.2 完整代码实现

4.2.1 Mutex.hpp（复用V1版本）

代码同V1版本，此处省略。

4.2.2 Logger.hpp（复用V1版本）

代码同V1版本，此处省略。

4.2.3 字典业务模块：Dictionary.hpp

#pragma once
#include <iostream>
#include <string>
#include <fstream>
#include <unordered_map>
#include "Logger.hpp"

std::string defaultdict = "./Dict.txt";
std::string gsep = ": ";

using namespace LogModule;

class Dictionary
{
private:
void LoadConf()
{
std::ifstream in(_dictfilename);
if (!in.is_open())
{
LOG(LogLevel::FATAL) << "Open dictionary file error: " << _dictfilename;
exit(1);
}

std::string line;
int line_num = 0;
while (std::getline(in, line))
{
line_num++;
if (line.empty()) continue;

auto pos = line.find(gsep);
if (pos == std::string::npos)
{
LOG(LogLevel::WARNING) << "Line " << line_num << " format error, skip: " << line;
continue;
}

std::string key = line.substr(0, pos);
std::string value = line.substr(pos + gsep.size());
_dictmap.insert({key, value});
}

in.close();
LOG(LogLevel::INFO) << "Load dictionary success, total " << _dictmap.size() << " words";
}

public:
Dictionary(const std::string &dictfilename = defaultdict)
: _dictfilename(dictfilename)
{
LoadConf();
}

std::string Translate(const std::string &word)
{
auto iter = _dictmap.find(word);
if(iter == _dictmap.end())
{
return "未知单词";
}
return iter->second;
}

~Dictionary() {}

private:
std::string _dictfilename;
std::unordered_map<std::string, std::string> _dictmap;
};

4.2.4 字典数据文件：Dict.txt

apple: 苹果 – I eat an apple every day. / 我每天吃一个苹果。
banana: 香蕉 – The monkey is eating a banana. / 猴子正在吃香蕉。
cat: 猫 – My cat likes to sleep on the sofa. / 我的猫喜欢在沙发上睡觉。
dog: 狗 – She takes her dog for a walk every morning. / 她每天早上带她的狗去散步。
book: 书 – This book is very interesting. / 这本书非常有趣。
pen: 笔 – May I use your pen? / 我可以用一下你的笔吗？
happy: 快乐的 – She looks very happy today. / 她今天看起来很快乐。
sad: 悲伤的 – He felt sad when he lost his watch. / 他丢了手表时感到很悲伤。
run: 跑 – I run fast in the park. / 我在公园里跑得很快。
jump: 跳 – The child can jump high. / 这个孩子能跳得很高。
teacher: 老师 – Our teacher is very kind. / 我们的老师非常和蔼。
student: 学生 – He is a hardworking student. / 他是一个勤奋的学生。
car: 汽车 – His car is very fast. / 他的汽车非常快。
bus: 公交车 – I go to school by bus. / 我乘公交车上学。
love: 爱 – I love my family. / 我爱我的家人。
hate: 恨 – I hate getting up early. / 我讨厌早起。
hello: 你好 – Hello, nice to meet you! / 你好，很高兴认识你！
goodbye: 再见 – Goodbye, see you tomorrow! / 再见，明天见！
summer: 夏天 – Summer is my favorite season. / 夏天是我最喜欢的季节。
winter: 冬天 – It is very cold in winter. / 冬天非常冷。

4.2.5 通用UDP服务器：UdpServer.hpp

#ifndef __UDP_SERVER_HPP
#define __UDP_SERVER_HPP
#include <iostream>
#include <string>
#include <strings.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <functional>
#include "Logger.hpp"

using namespace LogModule;

using callback_t = std::function<std::string(const std::string &)>;

class UdpServer
{
public:
UdpServer(callback_t cb, uint16_t port)
: _sockfd(–1),
_port(port),
_cb(cb)
{
}

void Init()
{
_sockfd = socket(AF_INET, SOCK_DGRAM, 0);
if (_sockfd < 0)
{
LOG(LogLevel::FATAL) << "Create socket error";
exit(1);
}
LOG(LogLevel::INFO) << "Create socket success, fd: " << _sockfd;

struct sockaddr_in local;
bzero(&local, sizeof(local));
local.sin_family = AF_INET;
local.sin_port = htons(_port);
local.sin_addr.s_addr = INADDR_ANY;

int n = bind(_sockfd, (struct sockaddr *)&local, sizeof(local));
if (n < 0)
{
LOG(LogLevel::FATAL) << "Bind socket error";
exit(2);
}
LOG(LogLevel::INFO) << "Bind socket success, port: " << _port;
}

void Start()
{
LOG(LogLevel::INFO) << "Udp Dictionary Server start running…";
char inbuffer[1024];
while (true)
{
struct sockaddr_in peer;
socklen_t len = sizeof(peer);

ssize_t n = recvfrom(_sockfd, inbuffer, sizeof(inbuffer) – 1, 0,
(struct sockaddr *)&peer, &len);
if (n < 0)
{
LOG(LogLevel::WARNING) << "Recvfrom error, errno: " << errno;
continue;
}

inbuffer[n] = '\\0';
std::string clientip = inet_ntoa(peer.sin_addr);
uint16_t clientport = ntohs(peer.sin_port);
LOG(LogLevel::INFO) << "Received from [" << clientip << ":" << clientport
<< "]: " << inbuffer;

std::string result;
if(_cb)
{
result = _cb(inbuffer);
}

sendto(_sockfd, result.c_str(), result.size(), 0,
(struct sockaddr *)&peer, len);
LOG(LogLevel::DEBUG) << "Sent response to [" << clientip << ":" << clientport
<< "]: " << result;
}
}

~UdpServer()
{
if (_sockfd >= 0)
{
close(_sockfd);
}
}

private:
int _sockfd;
uint16_t _port;
callback_t _cb;
};

#endif

4.2.6 服务器主函数：Main.cc

#include "UdpServer.hpp"
#include "Dictionary.hpp"
#include <memory>

void Usage(const std::string &proc)
{
std::cout << "Usage: \\n\\t" << proc << " local_port\\n" << std::endl;
}

int main(int argc, char *argv[])
{
if(argc != 2)
{
Usage(argv[0]);
return 1;
}

ENABLE_CONSOLE_LOG_STRATEGY();
// ENABLE_FILE_LOG_STRATEGY();

uint16_t port = std::stoi(argv[1]);

std::unique_ptr<Dictionary> dict = std::make_unique<Dictionary>();

std::unique_ptr<UdpServer> usvr = std::make_unique<UdpServer>(
[&dict](const std::string &word) -> std::string {
return dict->Translate(word);
},
port
);

usvr->Init();
usvr->Start();

return 0;
}

4.3 客户端代码（通用版）

#include <iostream>
#include <string>
#include <cstring>
#include <unistd.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>

void Usage(const std::string &process)
{
std::cout << "Usage: " << process << " server_ip server_port" << std::endl;
}

int main(int argc, char *argv[])
{
if (argc != 3)
{
Usage(argv[0]);
return 1;
}

std::string serverip = argv[1];
uint16_t serverport = std::stoi(argv[2]);

int sock = socket(AF_INET, SOCK_DGRAM, 0);
if (sock < 0)
{
std::cerr << "Create socket error: " << strerror(errno) << std::endl;
return 2;
}

struct sockaddr_in server;
memset(&server, 0, sizeof(server));
server.sin_family = AF_INET;
server.sin_port = htons(serverport);
server.sin_addr.s_addr = inet_addr(serverip.c_str());

std::cout << "=== UDP Dictionary Client ===" << std::endl;
std::cout << "Enter 'quit' to exit" << std::endl;

std::string word;
while (true)
{
std::cout << "\\nPlease enter a word: ";
std::getline(std::cin, word);

if (word == "quit" || word == "exit")
{
std::cout << "Goodbye!" << std::endl;
break;
}

if (word.empty()) continue;

sendto(sock, word.c_str(), word.size(), 0,
(struct sockaddr*)&server, sizeof(server));

char buffer[1024];
struct sockaddr_in temp;
socklen_t len = sizeof(temp);
ssize_t n = recvfrom(sock, buffer, sizeof(buffer)–1, 0,
(struct sockaddr*)&temp, &len);
if (n > 0)
{
buffer[n] = '\\0';
std::cout << "Result: " << buffer << std::endl;
}
else
{
std::cerr << "Recvfrom error" << std::endl;
}
}

close(sock);
return 0;
}

4.4 编译与运行

4.4.1 Makefile

CC = g++
STD = -std=c++17
CFLAGS = -Wall -g -lpthread -lstdc++fs

all: dict_server dict_client

dict_server: Main.cc
$(CC) -o $@ $^ $(STD) $(CFLAGS)

dict_client: DictClient.cc
$(CC) -o $@ $^ $(STD) $(CFLAGS)

.PHONY: clean
clean:
rm -f dict_server dict_client
rm -rf log/

4.4.2 运行步骤

4.5 V2版本优势总结

• 完全解耦：网络层与业务层完全分离，UdpServer可复用

• 生产级日志：支持控制台/文件双输出，线程安全

• 可扩展性强：字典数据从外部文件加载，无需修改代码即可扩展

• 完善的错误处理：文件错误、网络错误、格式错误均有处理

• 线程安全：所有共享资源访问均加锁保护

5 ~> V3版本：多人聊天室（生产级并发）

5.1 整体架构：生产者 – 消费者模型

我们采用经典的生产者-消费者分层架构，解决单线程性能瓶颈：

• 生产者层：UdpServer主线程，专门负责接收客户端UDP数据包（IO密集型，阻塞在recvfrom）

• 缓冲层：线程池内部的线程安全任务队列，解耦生产和消费速度，削峰填谷

• 消费者层：线程池中的多个工作线程，负责用户管理、消息路由和广播（CPU密集型）

5.2 核心模块补充

5.2.1 Cond.hpp（条件变量封装）

#ifndef __COND_HPP
#define __COND_HPP
#include <pthread.h>
#include "Mutex.hpp"

class Cond
{
public:
Cond()
{
pthread_cond_init(&_cond, nullptr);
}

void Wait(Mutex &mutex)
{
pthread_cond_wait(&_cond, mutex.Orgin());
}

void NotifyOne()
{
pthread_cond_signal(&_cond);
}

void NotifyAll()
{
pthread_cond_broadcast(&_cond);
}

~Cond()
{
pthread_cond_destroy(&_cond);
}

private:
pthread_cond_t _cond;
};

#endif

5.2.2 Thread.hpp（线程封装）

#ifndef __THREAD_HPP
#define __THREAD_HPP
#include <iostream>
#include <string>
#include <functional>
#include <pthread.h>
#include <unistd.h>
#include <sys/syscall.h>
#include "Logger.hpp"

using namespace LogModule;

using func_t = std::function<void()>;

enum class TSTATUS
{
THREAD_NEW,
THREAD_RUNNING,
THREAD_STOP
};

static int gcnt = 1;

class Thread
{
private:
void getprocessid()
{
_pid = getpid();
}

void getlwp()
{
_lwpid = syscall(SYS_gettid);
}

static void *routine(void *args)
{
Thread *ts = static_cast<Thread *>(args);
ts->getprocessid();
ts->getlwp();
pthread_setname_np(pthread_self(), ts->Name().c_str());
ts->_func();
return nullptr;
}

public:
Thread(func_t f) : _joinable(true), _status(TSTATUS::THREAD_NEW), _func(f)
{
_name = "Worker-" + std::to_string(gcnt++);
}

void start()
{
if (_status == TSTATUS::THREAD_RUNNING)
{
LOG(LogLevel::INFO) << "thread is already running";
return;
}
int n = pthread_create(&_tid, nullptr, routine, this);
(void)n;
_status = TSTATUS::THREAD_RUNNING;
}

void stop()
{
if (_status == TSTATUS::THREAD_RUNNING)
{
int n = pthread_cancel(_tid);
(void)n;
_status = TSTATUS::THREAD_STOP;
}
else
{
LOG(LogLevel::WARNING) << "thread status is : THREAD_NEW or THREAD_STOP! stop error";
}
}

void join()
{
if (_joinable)
{
int n = pthread_join(_tid, nullptr);
(void)n;
LOG(LogLevel::INFO) << "lwp : " << _lwpid << ", name: " << _name << ", join success";
}
else
{
LOG(LogLevel::WARNING) << "lwp : " << _lwpid << ", name: " << _name << ", join failed, because thread is detach";
}
}

void detach()
{
if (_joinable && _status == TSTATUS::THREAD_RUNNING)
{
_joinable = false;
int n = pthread_detach(_tid);
(void)n;
}
}

std::string Name()
{
return _name;
}

~Thread() {}

private:
pthread_t _tid;
pid_t _pid;
pid_t _lwpid;
std::string _name;
bool _joinable;
TSTATUS _status;
func_t _func;
};

#endif

5.2.3 InetAddr.hpp（地址封装）

#pragma once
#include <iostream>
#include <string>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>

#define CONV(addr) ((struct sockaddr*)(addr))

class InetAddr
{
public:
InetAddr(struct sockaddr_in &addr) : _net_addr(addr)
{
_port = ntohs(_net_addr.sin_port);
_ip = inet_ntoa(_net_addr.sin_addr);
}

InetAddr(uint16_t port, std::string ip = "0.0.0.0")
: _port(port), _ip(ip)
{
_net_addr.sin_family = AF_INET;
_net_addr.sin_port = htons(_port);
_net_addr.sin_addr.s_addr = inet_addr(_ip.c_str());
}

uint16_t Port() { return _port; }
std::string Ip() { return _ip; }

struct sockaddr *Addr()
{
return CONV(&_net_addr);
}

bool operator==(const InetAddr &addr)
{
return (_ip == addr._ip) && (_port == addr._port);
}

socklen_t AddrLen()
{
return sizeof(_net_addr);
}

std::string StringAddress()
{
return "[" + _ip + ":" + std::to_string(_port) + "]";
}

~InetAddr()
{
}

private:
uint16_t _port;
std::string _ip;
struct sockaddr_in _net_addr;
};

5.2.4 Route.hpp（消息路由）

#pragma once
#include <iostream>
#include <vector>
#include <string>
#include <algorithm>
#include "InetAddr.hpp"
#include "Mutex.hpp"
#include "Logger.hpp"

using namespace LogModule;

class Route
{
private:
bool IsOnline(const InetAddr &who)
{
for (auto &user : _users)
{
if (user == who)
return true;
}
return false;
}

void AddUser(const InetAddr &who)
{
_users.push_back(who);
LOG(LogLevel::INFO) << "New user online: " << who.StringAddress();
}

void DeleteUser(const InetAddr &who)
{
auto iter = std::remove_if(_users.begin(), _users.end(),
[&who](const InetAddr &user)
{ return user == who; });
if (iter != _users.end())
{
_users.erase(iter, _users.end());
LOG(LogLevel::INFO) << "User offline: " << who.StringAddress();
}
}

public:
Route() {}

void RouteMessage(std::string message, InetAddr who, int sockfd)
{
LOG(LogLevel::DEBUG) << "3. RouteMessage";
std::vector<InetAddr> temp_users;

{
LockGuard lockguard(&_lock);
if (!IsOnline(who))
{
AddUser(who);
}
temp_users = _users;
};

std::string send_message = who.StringAddress() + "# " + message;
for (auto &user : temp_users)
{
ssize_t ret = sendto(sockfd, send_message.c_str(), send_message.size(), 0, user.Addr(), user.AddrLen());
if (ret < 0)
{
LOG(LogLevel::WARNING) << "sendto error: " << user.StringAddress();
}
}

if (message == "QUIT")
{
LockGuard lockguard(&_lock);
DeleteUser(who);
}
}

~Route() {}

private:
std::vector<InetAddr> _users;
Mutex _lock;
};

5.2.5 UdpServer.hpp（聊天室专用版）

#ifndef __UDP_SERVER_HPP
#define __UDP_SERVER_HPP
#include <iostream>
#include <string>
#include <strings.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <functional>
#include "InetAddr.hpp"
#include "Logger.hpp"

using namespace LogModule;

using callback_t = std::function<void(std::string message, InetAddr who, int sockfd)>;

class UdpServer
{
public:
UdpServer(callback_t cb, uint16_t port)
: _sockfd(–1),
_port(port),
_cb(cb)
{
}

void Init()
{
_sockfd = socket(AF_INET, SOCK_DGRAM, 0);
if (_sockfd < 0)
{
LOG(LogLevel::FATAL) << "create socket error";
exit(1);
}
LOG(LogLevel::INFO) << "create socket fd success: " << _sockfd;

InetAddr local(_port);
int n = bind(_sockfd, local.Addr(), local.AddrLen());
if (n < 0)
{
LOG(LogLevel::FATAL) << "bind socket error";
exit(2);
}
LOG(LogLevel::INFO) << "bind socket fd success: " << _sockfd;
}

void Start()
{
char inbuffer[1024];
while (true)
{
struct sockaddr_in peer;
socklen_t len = sizeof(peer);
ssize_t n = recvfrom(_sockfd, inbuffer, sizeof(inbuffer) – 1, 0, (struct sockaddr *)&peer, &len);
if (n < 0)
{
LOG(LogLevel::WARNING) << "recvfrom error";
break;
}
inbuffer[n] = 0;
InetAddr clientaddr(peer);
if (_cb)
{
_cb(inbuffer, clientaddr, _sockfd);
}
}
}

~UdpServer()
{
if (_sockfd >= 0)
{
close(_sockfd);
_sockfd = –1;
}
}

private:
int _sockfd;
uint16_t _port;
callback_t _cb;
};

#endif

5.2.6 ThreadPool.hpp（懒汉单例线程池）

#pragma once
#include <iostream>
#include <vector>
#include <queue>
#include "Thread.hpp"
#include "Logger.hpp"
#include "Mutex.hpp"
#include "Cond.hpp"

static const int gnum = 5;

using namespace LogModule;

template <typename T>
class ThreadPool
{
private:
bool IsTaskQueueEmpty()
{
return _queue.empty();
}

T PopHelper()
{
T t = _queue.front();
_queue.pop();
return t;
}

void ThreadRoutine()
{
char name[64];
pthread_getname_np(pthread_self(), name, sizeof(name));
while (true)
{
T task;
{
LockGuard lockguard(&_lock);
while (IsTaskQueueEmpty() && _isrunning)
{
_sleeper_cnt++;
LOG(LogLevel::DEBUG) << "没有任务, 线程休眠: |" << name << "|";
_cond.Wait(_lock);
LOG(LogLevel::DEBUG) << "有任务, 线程唤醒: |" << name << "|";
_sleeper_cnt—;
}
if (IsTaskQueueEmpty() && !_isrunning)
{
LOG(LogLevel::INFO) << "Thread: " << name << " quit";
break;
}
task = PopHelper();
}
task();
}
}

ThreadPool(int num = gnum) : _num(num), _isrunning(false), _sleeper_cnt(0)
{
for (int i = 0; i < _num; i++)
{
_threads.emplace_back([this]()
{
this->ThreadRoutine();
});
}
}

ThreadPool(const ThreadPool<T> &) = delete;
ThreadPool<T> &operator=(const ThreadPool<T> &) = delete;

public:
static ThreadPool<T> *GetInstance()
{
if (_instance == nullptr)
{
LockGuard lockguard(&_singleton_lock);
if (_instance == nullptr)
{
LOG(LogLevel::DEBUG) << "首次使用，创建线程池对象";
_instance = new ThreadPool<T>();
_instance->Start();
}
}
return _instance;
}

void Start()
{
LockGuard lockguard(&_lock);
if (_isrunning)
return;
_isrunning = true;
for (auto &thread : _threads)
thread.start();
}

void Enqueue(T task)
{
LockGuard lockguard(&_lock);
if (!_isrunning)
return;
_queue.push(task);
if (_sleeper_cnt > 0)
_cond.NotifyOne();
LOG(LogLevel::DEBUG) << "2. Enqueue task";
}

void Stop()
{
LockGuard lockguard(&_lock);
if (_isrunning)
{
LOG(LogLevel::DEBUG) << "关闭线程池";
_isrunning = false;
if (_sleeper_cnt > 0)
_cond.NotifyAll();
}
}

void Wait()
{
for (auto &thread : _threads)
thread.join();
}

~ThreadPool() {}

private:
std::vector<Thread> _threads;
int _num;
bool _isrunning;
int _sleeper_cnt;
std::queue<T> _queue;
Mutex _lock;
Cond _cond;
static ThreadPool<T> *_instance;
static Mutex _singleton_lock;
};

template <typename T>
ThreadPool<T> *ThreadPool<T>::_instance = nullptr;

template <typename T>
Mutex ThreadPool<T>::_singleton_lock;

5.3 主函数整合

#include <iostream>
#include <signal.h>
#include <unistd.h>
#include "UdpServer.hpp"
#include "Route.hpp"
#include "ThreadPool.hpp"
#include "Logger.hpp"

using namespace LogModule;

static Route g_route;

void StopHandler(int signo)
{
LOG(LogLevel::INFO) << "recv signal: " << signo << ", stop chatroom…";

ThreadPool<std::function<void()>>::GetInstance()->Stop();
ThreadPool<std::function<void()>>::GetInstance()->Wait();

LOG(LogLevel::INFO) << "chatroom stop success!";
exit(0);
}

int main(int argc, char *argv[])
{
if (argc != 2)
{
std::cerr << "Usage: " << argv[0] << " <port>" << std::endl;
return 1;
}

ENABLE_CONSOLE_LOG_STRATEGY();
// ENABLE_FILE_LOG_STRATEGY();

signal(SIGINT, StopHandler);
signal(SIGTERM, StopHandler);

uint16_t port = std::stoi(argv[1]);

auto *tp = ThreadPool<std::function<void()>>::GetInstance();

UdpServer server
(
[&g_route, tp](std::string message, InetAddr who, int sockfd)
{
LOG(LogLevel::INFO) << "1. get a message: " << message
<< ", client addr: " << who.Ip() << ":" << who.Port();
auto task = [message, who, sockfd, &g_route]()
{
g_route.RouteMessage(message, who, sockfd);
};
tp->Enqueue(task);
},
port
);

server.Init();

LOG(LogLevel::INFO) << "chatroom start success! port: " << port;

server.Start();

return 0;
}

5.4 编译与运行

5.4.1 Makefile

CC = g++
STD = -std=c++17
CFLAGS = -Wall -g -lpthread -lstdc++fs

all: chat_server chat_client

chat_server: ChatMain.cc
$(CC) -o $@ $^ $(STD) $(CFLAGS)

chat_client: ChatClient.cc
$(CC) -o $@ $^ $(STD) $(CFLAGS)

.PHONY: clean
clean:
rm -f chat_server chat_client
rm -rf log/

5.4.2 运行步骤

make
./chat_server 8888
nc -u 127.0.0.1 8888

5.5 客户端实现：多线程收发分离

5.5.1 Linux客户端

#include <iostream>
#include <string>
#include <thread>
#include <cstring>
#include "InetAddr.hpp"
#include <sys/socket.h>
#include <unistd.h>

int sockfd = –1;
std::string server_ip;
uint16_t server_port = 0;

void Usage(const std::string& name)
{
std::cerr << "Usage: " << name << " server_ip server_port" << std::endl;
}

void RecvMessage()
{
char buffer[4096];
while (true)
{
struct sockaddr_in temp;
socklen_t len = sizeof(temp);
ssize_t n = recvfrom(sockfd, buffer, sizeof(buffer)–1, 0,
(struct sockaddr*)&temp, &len);
if (n > 0)
{
buffer[n] = '\\0';
std::cerr << buffer << std::endl;
}
}
}

void SendMessage()
{
InetAddr server_addr(server_port, server_ip);
std::string line;
while (true)
{
std::cout << "Please Enter# ";
std::getline(std::cin, line);
if (line.empty()) continue;
sendto(sockfd, line.c_str(), line.size(), 0,
server_addr.Addr(), server_addr.AddrLen());

if (line == "QUIT")
{
std::cout << "Goodbye!" << std::endl;
close(sockfd);
exit(0);
}
}
}

int main(int argc, char* argv[])
{
if (argc != 3)
{
Usage(argv[0]);
exit(0);
}
server_ip = argv[1];
server_port = std::stoi(argv[2]);

sockfd = socket(AF_INET, SOCK_DGRAM, 0);
if (sockfd < 0)
{
std::cerr << "Create socket error" << std::endl;
exit(1);
}

std::thread recv_thread(RecvMessage);
std::thread send_thread(SendMessage);

recv_thread.join();
send_thread.join();

close(sockfd);
return 0;
}

6 ~> 工程化实践与踩坑总结

6.1 日志系统使用指南

• 默认控制台日志：程序启动时自动启用

• 切换到文件日志：在main函数开头调用ENABLE\\_FILE\\_LOG\\_STRATEGY\\(\\)

• 日志等级：从低到高为DEBUG &lt; INFO &lt; WARNING &lt; ERROR &lt; FATAL

• 日志格式：\\[时间\\] \\[等级\\] \\[进程ID\\] \\[文件名\\] \\[行号\\] \\- 日志内容

6.2 UDP编程踩坑总结

6.2.1 基础API踩坑

6.2.2 多线程踩坑

6.2.3 业务逻辑踩坑

6.3 客户端访问服务端，云服务器需要开放一些端口

为保障云服务器安全，厂商已通过防火墙对所有端口进行了限制处理，导致客户端无法正常访问服务器端口。若需解决该问题，可在防火墙或安全组中开放云服务器的端口（建议开放8000~9000端口范围），相关操作有对应视频教程，完成端口开放后，客户端即可正常访问服务器。

7 ~> 总结与后续优化方向

7.1 本文总结

我们完成了UDP编程从入门到生产级的完整演进：

• 从V1的Echo服务器掌握了基础Socket收发

• 从V2的增强版字典服务器学会了生产级工程化实践（日志、配置、解耦）

• 从V3的聊天室掌握了多用户管理、并发优化和跨平台通信

7.2 后续优化方向

附录：完整项目文件结构

udp_project/
├── V1-Echo/
│ ├── Mutex.hpp
│ ├── Logger.hpp
│ ├── UdpEchoServer.hpp
│ ├── main.cpp
│ └── Makefile
├── V2-Dictionary/
│ ├── Mutex.hpp
│ ├── Logger.hpp
│ ├── Dictionary.hpp
│ ├── UdpServer.hpp
│ ├── Main.cc
│ ├── DictClient.cc
│ ├── Dict.txt
│ └── Makefile
├── V3-ChatRoom/
│ ├── Mutex.hpp
│ ├── Logger.hpp
│ ├── Cond.hpp
│ ├── Thread.hpp
│ ├── InetAddr.hpp
│ ├── Route.hpp
│ ├── UdpServer.hpp
│ ├── ThreadPool.hpp
│ ├── ChatMain.cc
│ ├── ChatClient.cc
│ └── Makefile
└── README.md

结尾

uu们，本文的内容到这里就全部结束了，艾莉丝在这里再次感谢您的阅读！

结语：希望对学习Linux相关内容的uu有所帮助，不要忘记给博主“一键四连”哦！

往期回顾：

【Linux网络】Linux 网络编程入门：UDP Socket 编程（上）

🗡博主在这里放了一只小狗，大家看完了摸摸小狗放松一下吧！🗡

૮₍ ˶ ˊ ᴥ ˋ˶₎ა
