统一 GPU 池结合队列与调度策略：实现 K8s 容器化下多模型服务的高效调度与资源池化

统一 GPU 池结合队列与调度策略：实现 K8s 容器化下多模型服务的高效调度与资源池化

引言

在云原生大模型平台中，通常需要同时部署多个不同规格的模型服务，这些模型对 GPU 资源的需求各不相同。如果每个模型独立分配 GPU 资源，会导致资源利用率低下。如何构建统一的 GPU 资源池，结合智能的队列与调度策略，实现多模型服务的高效调度与资源池化，是提升整体资源利用率的关键。

本文将深入探讨如何在 Kubernetes 容器化环境下，构建统一 GPU 资源池，结合队列与调度策略，实现多模型服务的高效调度与资源池化。

二、 GPU 资源池的调度策略

1.1 GPU 池架构设计

flowchart TB
subgraph Models [模型服务]
A[模型A – 7B]
B[模型B – 13B]
C[模型C – 70B]
end

subgraph ControlPlane [控制平面]
D[中央调度器]
E[队列管理器]
F[优先级控制器]
end

subgraph NodePools [节点池]
G[节点池-通用型]
H[节点池-高性能型]
I[节点池-推理专用型]
end

A –> D
B –> D
C –> D
D –> E
E –> F
F –> G
F –> H
F –> I

1.2 调度策略与资源配置

三、 模型规格的资源需求

2.1 不同规格模型的资源需求

apiVersion: inference.example.com/v1
kind: ModelServingSpec
metadata:
name: llama-7b
spec:
modelFamily: "llama"
modelSize: "7b"
resources:
gpuMemory: "13Gi"
cpu: "2"
memory: "16Gi"
autoscaling:
minReplicas: 2
maxReplicas: 20
targetConcurrency: 100
placementConstraints:
nodeTypes: ["a10g", "a100"]
toleratePreemptible: true
schedulingClass: "medium-priority"
—
apiVersion: inference.example.com/v1
kind: ModelServingSpec
metadata:
name: llama-70b
spec:
modelFamily: "llama"
modelSize: "70b"
resources:
gpuMemory: "140Gi"
cpu: "8"
memory: "64Gi"
autoscaling:
minReplicas: 1
maxReplicas: 5
targetConcurrency: 20
placementConstraints:
nodeTypes: ["a100-80gb", "h100"]
toleratePreemptible: false
schedulingClass: "high-priority"

2.2 资源池配置

apiVersion: gpu.example.com/v1
kind: ResourcePool
metadata:
name: general-purpose
spec:
nodeSelector:
gpu.type: "a10g"
capacity:
totalGPUs: 32
availableGPUs: 28
taints:
– key: "gpu-pool"
value: "general-purpose"
effect: "NoSchedule"
tolerations:
– key: "gpu-pool"
value: "general-purpose"
schedulingPolicy:
binPack: true
overcommitRatio: 1.2
—
apiVersion: gpu.example.com/v1
kind: ResourcePool
metadata:
name: high-performance
spec:
nodeSelector:
gpu.type: "a100"
capacity:
totalGPUs: 16
availableGPUs: 12
schedulingPolicy:
binPack: false
spread: true
overcommitRatio: 1.0

四、 队列与调度

3.1 调度队列实现

package scheduler

import (
"context"
"container/heap"
"fmt"
"sync"

corev1 "k8s.io/api/core/v1"
metav1 "k8s.io/apimachinery/pkg/apis/meta/v1"
"k8s.io/klog/v2"
)

type PriorityQueue struct {
mu sync.Mutex
items []*QueueItem
itemMap map[string]*QueueItem
}

type QueueItem struct {
Pod *corev1.Pod
Priority int
EnqueueAt metav1.Time
index int
}

func NewPriorityQueue() *PriorityQueue {
pq := &PriorityQueue{
items: make([]*QueueItem, 0),
itemMap: make(map[string]*QueueItem),
}
heap.Init(pq)
return pq
}

func (pq *PriorityQueue) Enqueue(pod *corev1.Pod, priority int) {
pq.mu.Lock()
defer pq.mu.Unlock()

key := fmt.Sprintf("%s/%s", pod.Namespace, pod.Name)
item := &QueueItem{
Pod: pod,
Priority: priority,
EnqueueAt: metav1.Now(),
}

heap.Push(pq, item)
pq.itemMap[key] = item

klog.Infof("Pod %s enqueued with priority %d", key, priority)
}

func (pq *PriorityQueue) Dequeue() (*corev1.Pod, bool) {
pq.mu.Lock()
defer pq.mu.Unlock()

if len(pq.items) == 0 {
return nil, false
}

item := heap.Pop(pq).(*QueueItem)
key := fmt.Sprintf("%s/%s", item.Pod.Namespace, item.Pod.Name)
delete(pq.itemMap, key)

return item.Pod, true
}

3.2 调度策略配置

apiVersion: v1
kind: ConfigMap
metadata:
name: gpu-scheduler-config
namespace: kube-system
data:
scheduler-config.yaml: |
queues:
– name: "high-priority"
priority: 100
weight: 50
maxPending: 100

– name: "medium-priority"
priority: 50
weight: 30
maxPending: 200

– name: "low-priority"
priority: 10
weight: 20
maxPending: 500

schedulingPolicy:
binPack: true
topologyAware: true
gangScheduling: true
preemptionEnabled: true

五、 Bin Packing 与 Topology Aware

4.1 Bin Packing 策略实现

package binpacking

import (
"sort"

corev1 "k8s.io/api/core/v1"
)

type NodeScore struct {
Node *corev1.Node
Score float64
}

func CalculateBinPackScore(node *corev1.Node, pod *corev1.Pod) float64 {
// 计算剩余空间
totalGPU := getTotalGPUMemory(node)
usedGPU := getUsedGPUMemory(node)
remainingGPU := totalGPU – usedGPU

// 计算填充率
fillRatio := float64(usedGPU) / float64(totalGPU)

// 优先选择填充率高的节点
return fillRatio*0.7 + (1 – remainingGPU/totalGPU)*0.3
}

func RankNodesByBinPack(nodes []*corev1.Node, pod *corev1.Pod) []*corev1.Node {
scores := make([]NodeScore, 0, len(nodes))

for _, node := range nodes {
if !canFit(node, pod) {
continue
}
score := CalculateBinPackScore(node, pod)
scores = append(scores, NodeScore{Node: node, Score: score})
}

sort.Slice(scores, func(i, j int) bool {
return scores[i].Score > scores[j].Score
})

ranked := make([]*corev1.Node, 0, len(scores))
for _, s := range scores {
ranked = append(ranked, s.Node)
}

return ranked
}

六、 最佳实践

总结

统一 GPU 池的调度核心在于:按模型规格(7B/13B/70B)映射到不同 GPU 节点池,通过 Bin Packing 最大化单卡利用率,Topology Aware 减少跨卡通信。队列按优先级加权分配,70B 模型抢占队列头部。通过这种调度策略,可以将整体 GPU 利用率提升至 70% 以上。
